SHERP N 1200

The most advanced 4WD business
solution ever built.

Off-road Vehicle Unrivaled Throughout the World

Untitled design (18).png

Unstoppable

Capable of driving dense forests, fallen trees, shaky grounds, gravel, peat, moor, marsh, dunes, swamps, boulders, scree, snow, ice and more.


Floats Anywhere

Floats constantly at any depth: pounds, lakes, rivers, shores, coasts and frozen waters.


Climbs Everywhere

The only wheeled vehicle to climb from waters onto the ice. Able on up to 3,000 m over sea level and overcome obstacles up to 1 m in height.

Technical Specifications

Untitled design (19).png
Untitled design (10).png

1.8 L

Diesel Engine

6-Speed

Manual Gearbox

55 HP

190 N•m

Power

Torque

Max Speed: Land

40 km/h  (25 mph)

Grass, gravel, sand, peat, moor, marsh, sand, dunes, rocks, scree, snow, ice, climbing from water to ice.

Max Speed: Water

6 km/h  (3.7 mph)

Ponds, lakes, rivers, sandbanks, shores, coasts, and frozen waters.

Fuel Autonomy

Fuel Tank 95 L  (25 gal)

Ability to drive for 14 hours non-stop.

+4 Fuel Canisters 232 L  (61.2 gal)

Ability to drive for approx. 61 hours non-stop.

Exterior

Untitled design (20).png

Extended Lifetime

Corrosion resistance due to galvanized steel body.

Aluminum Upper Body

Lighter vehicle and low center of gravity.


3 Points of Support

At the front and back door.

Rear-View Camera

Allows the driver to control the environment behind.

SHERP N 1200 Body Options


Hard Top

2 Side Windows

4 Side Windows

Interior


Ergonomic Seats

Ensure comfortable ride even on harsh terrains.


Crew Carrier

Able to carry 9 people, including driver.

DSC01792-1 (1).webp

Cargo Carrier

5.8 M³ of volume available in rear compartment.


4-Point Seatbelts

Guarantee the safety of the driver and passengers.


Foldable Back Seats

Use SHERP as both a crew and cargo carrier.


Control Panel

Convenient and thoughtfully designed system of switches allows the control of SHERP.

SHERP N 1200 Interior Options


No Seats / Cargo


2 Back Seats


4 Back Seats


7 Back Seats

Any Season. Any Weather Conditions. Any Terrain.

SHERP N 1200 Advantages


One-Vehicle Off-Road Solution

Universal logistics solution - substitutes an ATV, a snowmobile, a boat, a hovercraft, and manpower.  Is sure to transport people and cargo to their destinations no matter the weather and terrain.


Low Cost Off-Road Operation

An off-road transportation of 2,640 LB of cargo by SHERP is 75% cheaper compared to transportation by cargo helicopter. Average hourly operating cost of $7/hour.


Best Off-Road Autonomy

Total fuel capacity of 327 L (86.3 gal) due to additional fuel tanks integrated into each wheel disk. Up to 65 hours of autonomous work and 19 hours of non-stop running.


High Capacities

Total loading capacity of 1,200 KG (2,645 LB),  which can increase to 2,100 KG (4,600LB) with additional universal cargo trailer. Passenger capacity of up to 9 people including a driver. Towing capacity of 2,350 KG (5,180 LB).


Warranty & Service

SHERP UTV is reliable and maintenance-friendly, so it can be repaired at any place. Manufacturer's warranty of 12 months or 2000 m/h (whichever comes first). 24/7 customer support around the world.

SHERP Innovations and Technologies

Tires are less liable to damage due to their elasticity, and if damaged, the tire puncture can be easily repaired in the field. The four tires are interconnected by a special "eco-circuit" and pumped up by the exhaust gases. Due to this technology, the wheels act as a suspension. The system does not need any air compressor, so it keeps the SHERP light and reliable. The patented design of the wheel and its tread provide a high level of adhesion to the ground and allow propulsion on the water.

Survival Endurance: Ultra-Low Pressure Tires


Design solutions and excellent materials allow achieving a minimum mass at maximum performance of the transported payload. Unlike hydraulic motors and belt drives, a unique experience of using chain gears helps to avoid slippage and sticking on any terrain when the vehicle is driving under extreme conditions.

TRANSMISSION CHAIN


Doosan Infracore diesel engine provides high torque and fuel efficiency with a low level of noise and vibration. The engines are adapted for work in any climate zone, which makes it possible to operate the all-terrain vehicle both in hot desert conditions or on a cold glacier. This eco-friendly, high efficient and optimum performance engine adds value to the customer as well as environment. The engine also meets the requirements of Stage V/Tier-4 final emission standards and delivers the power of 55 HP.

Efficient & Eco-Friendly Engine


Parts are made of DOCOL steel, which is resistant to deformation due to high yield strength (1000 MPa), which indicates its strength and resistance to deformation. The heart of SHERP all-terrain vehicle is the engine of the Japanese company Kubota, which has specialized in the manufacture of high-tech diesel engines for 120 years. The transmission is equipped with a manual gearbox RENAULT (JR5), which has shown its best side in terms of reliability, smooth shifting and gear ratios.

TOP QUALITY MANUFACTURING


Side-turn steering deprives SHERP of costly vulnerabilities specific to classic steering systems. The friction mechanism employed by SHERP makes turning easier. It is equipped with hydraulic steering system, so less driver efforts are needed when maneuvering. The turning mechanism is reliable and simple.

SKID STEERING


A unique patented solution - compressor-less tire inflation system. Ensure flawless operation no matter any external conditions. The SHERP's suspension has no springs or shock absorbers. Fewer parts means fewer breakdowns, better durability, and lower repair costs.

Less is More


A low center of gravity decreases the rollover risk. The body design includes integrated a Roll Over Protection System made of steel. All seats are equipped with adjustable two, three, and four-point seatbelts.

Safety First


The cabin has a large windshield and side windows that provide excellent visibility and allow assessing and reacting to the most extreme situations in a split second.

High Field of Visibility


Such maneuverability is essential in the wild, where each centimeter can be crucial. This feature makes it possible to move through dense forests and limited space areas.

360° Turn Almost on the Spot
